Series RV Bypass Valves

In-line design Bypass/Pressure Relief Valves for a wide variety of industrial services.  Adjustable differential pressure is attained for accurate and repeatable performance in return-to-tank or bypass systems.  This enables full pump flow whilst maintaining controlled preset maximum pressure.  Suitable for a wide range of services from LPG to bitumen.  Manufactured to Australian Standards and Codes.
Constructional Features
  • 90° flanged porting.
  • Screwed Ports (certain models).
  • Adjustable pressure setting within spring range.
  • Low Pressure rise.
Materials of Construction
  • Casing - Cast Iron, Ductile Iron, Steel.
  • Special materials to specification
Range of performance
Flows to 40 L/s
Diff. Pressures to 2000 kPa
Temperatures from -40°C to 350°C
